IEC 60317-19:2000 outlines the requirements for Class 1 30 solderable enameled round copper winding wire with a dual coating system. The base coating is formulated from polyurethane resin, which can be modified as long as it maintains the chemical composition of the original resin and complies with all the specified wire requirements. The outer coating […]
IEC 60317-19:2000 pdf download Read More »
IEC 60310:2004 is intended for traction transformers installed on rolling stock and for various types of inductors that are inserted into the power and auxiliary circuits of electric vehicles. NOTE 1: The term “inductor” in this standard is synonymous with the term “reactor” as referenced in IEC 60050(421), IEC 60050(811), and IEC 60289. The inductors
IEC 60310:2004 pdf download Read More »
IEC 60299:2014 is applicable to electric blankets, wraps, and duvets designed for household use. It outlines the key performance characteristics of these products and specifies the methods for measuring them, providing essential information for users. However, this standard does not establish specific values for these performance characteristics. NOTE: Safety requirements are addressed separately in IEC
IEC 60299:2014 pdf download Read More »
IEC 60296:2020 establishes the specifications and testing procedures for both unused and recycled mineral insulating oils (definitions can be found in Clause 3). It is relevant to mineral oil that is supplied under contractual terms and is intended for use in transformers, switchgear, and comparable electrical equipment where oil is necessary for insulation and heat
IEC 60296:2020 pdf download Read More »
IEC 60294:2012 is applicable to cylindrical capacitors and resistors intended for use in electronic equipment. It outlines measurement methods for determining the body length and for assessing any excessive protective coating that may extend onto the wire terminations of components featuring axial wire terminations. Additionally, it provides a procedure for measuring the overall body diameter
IEC 60294:2012 pdf download Read More »
This section of IEC 60286 pertains to bulk case packaging that can accommodate surface mounting components. The bulk case is intended for the transportation and storage of components, as well as for supplying them directly or via an appropriate feeder to the placement machine. It connects to the automatic handling machine through a coupling interface.
IEC 60286-6:2004 pdf download Read More »
This section of IEC 60286 applies to the tape packaging of components with axial leads designed for use in electronic equipment. Typically, the tape is applied to the component leads. It outlines requirements for tape-applying techniques used with equipment for lead preforming, automatic handling, insertion, and other operations. The standards only include dimensions essential to
IEC 60286-1:2021 pdf download Read More »
This section of IEC 60254 applies to lead-acid traction batteries utilized as power sources for electric propulsion. The purpose of this standard is to define the following: The maximum external dimensions of traction battery cells, including width, height, and length. The format for marking the polarity of traction battery cells, along with the dimensions of
IEC 60254-2:2008 pdf download Read More »
This section of IEC 60243 provides additional requirements beyond those specified in IEC 60243-1, pertaining to the assessment of the electrical strength of solid insulating materials when subjected to direct voltage stress.
IEC 60243-2:2013 pdf download Read More »
IEC 60228:2004 specifies the nominal cross-sectional areas for conductors in electric power cables and cords of a wide range of types, ranging from 0.5 mm² to 2500 mm². It also includes requirements for the numbers and sizes of wires and resistance values. These conductors include solid and stranded copper, aluminum, and aluminum alloy conductors for
IEC 60228:2004 pdf download Read More »
