This section of IEC 60317 lays out the specifications for enamelled rectangular copper winding wire, specifically designed for Class 240, with a single layer of aromatic polyimide resin.
The range of nominal conductor dimensions covered by this standard is:
- Width: minimum 2.0 mm, maximum 16.0 mm;
- Thickness: minimum 0.80 mm, maximum 5.60 mm.
Wires classified as grade 1 and grade 2 are included in this specification and apply to the full range of conductors.
The specified combinations of width and thickness, along with the width/thickness ratio, are detailed in IEC 60317-0-2.
