ASME Standards

This Standard covers overall dimensions, tolerances,ratings, testing, and markings for wrought factory-made buttwelding fittings in sizes NPS ‘/2 through 48 (DN 15 through 1200).

(1) flanges and flanged fittings made from cast or forged materials (2) blind flanges and certain reducing flanges made from cast, forged, or plate materials Also included in this Standard are requirements recommendations regarding flange bolting, gaskets, and joints.

This Standard for gray iron threaded fittings,Classes 125 and 250, covers (a) pressure–temperature ratings (b) sizes and method of designating openings of reducing fittings (c) marking (d) material (e) dimensions and tolerances (f) threading (g) coatings Mandatory Appendix I provides table values in U.S. Customary units.

This Standard covers malleable iron threaded fittings, Classes 150 and 300. It also contains provisions for using steel for caps and couplings in Class 150 for NPS 3 ⁄ 8 and smaller. This Standard includes (a) pressure–temperature ratings (b) size and method ofdesignating openings ofreduc-ing fittings (c) marking (d) material (e) dimensions and tolerances (f)

This Standard covers Classes 25, 125, and 250 Gray Iron Pipe Flanges and Flanged Fittings. It includes (a) pressure–temperature ratings (b) sizes and method of designating openings of reducing fittings (c) marking (d) materials (e) dimensions and tolerances (f) bolting and gaskets (g) pressure testing

This Standard covers Classes 25, 125, and 250 Gray Iron Pipe Flanges and Flanged Fittings. It includes (a) pressure–temperature ratings (b) sizes and method of designating openings of reducing fittings (c) marking (d) materials (e) dimensions and tolerances (f) bolting and gaskets (g) pressure testing

This Part of the ASME B5.60 standard covers the General Description and Definitions of Terms related to jaw type workholding chucks.

This Standard pertains to the standardization of basic toolholder shank, retention knob, and socket assemblies for numerically controlled machining centers with auto-matic tool changers. The requirements contained herein are intended to provide toolholder interchangeability between machining centers with automatic tool chang-ers of various types. This Standard is the inch solution for basic toolholder shank, retention

The purpose of this Standard is to establish uniform and specific practices for calculating and rounding the numeric values used for inch and metric screw thread design data dimensions only. No attempt is made to establish a policy of rounding actual thread characteris-tics measured by the manufacturer or user of thread gages. Covered is the
